Digital Addressable
Neon Flex
Pixel-level RGB and RGBW control for architectural lighting, signage, and dynamic installations. All profiles share the same silicone construction, IP67 weatherproofing, and 24V DC input — with built-in IC chips for DMX512 or SPI control. Choose from Top-Bend, Side-Bend, 3D, and 360° profiles to match your project geometry.
What Is Digital Addressable Neon Flex?
Each pixel segment is individually controlled via a built-in IC chip. Unlike standard RGB neon flex that changes color uniformly along the entire run, addressable neon flex lets you set different colors, brightness, and animation effects on each segment — pixel by pixel.
Per-Pixel Color Control
Each pixel segment runs its own color and brightness value. Chase effects, rainbow fades, zone mapping — all handled at the hardware level.
DMX512 & SPI Compatible
Works directly with professional lighting controllers. DMX512 for stage and architectural systems; SPI for LED-specific decoders and microcontrollers.
Same Silicone Build
Identical IP67 silicone construction as standard neon flex. IC chip is embedded inside the profile — no external control module per meter required.
Choose Your Profile
All four series share the same IC-controlled core. Choose the profile that matches your bending direction and installation geometry.
Top-Bend Addressable
Bends in the vertical plane — ideal for curved signage letters, channel letters, and outlines where the flex curves up and down along the installation surface.
Side-Bend Addressable
Bends horizontally — the most versatile profile for flat layouts, wall-mount curves, floor patterns, and cove lighting where the flex runs flat against a surface.
3D Addressable
Bends in all directions simultaneously — suitable for complex 3D sculptural shapes, twisted installations, and decorative forms that require multi-axis flexibility.
360° Round Addressable
Cylindrical profile with full 360° emission. Visible from any viewing angle — ideal for freestanding shapes, sculptural tube lighting, and installations seen from multiple directions.
Full Specifications
All models — 24V DC · IP67 Silicone · CRI >90 · -20°C to +55°C · 30,000 hrs lifespan
| Series | Model | Size (W×H mm) | Bend | Color | Voltage | Control | IP | CRI | Lifespan | Temp Range |
|---|---|---|---|---|---|---|---|---|---|---|
| TB | RH-NF-TB-1212-RGB-IC | 12 × 12 | Top | RGB | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| TB | RH-NF-TB-1212-RGBW-IC | 12 × 12 | Top | RGBW | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| TB | RH-NF-TB-1616-RGB-IC | 16 × 16 | Top | RGB | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| TB | RH-NF-TB-1616-RGBW-IC | 16 × 16 | Top | RGBW | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| SB | RH-NF-SB-0612-RGB-IC | 6 × 12 | Side | RGB | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| SB | RH-NF-SB-0612-RGBW-IC | 6 × 12 | Side | RGBW | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| SB | RH-NF-SB-0817-RGB-IC | 8 × 17 | Side | RGB | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| SB | RH-NF-SB-0817-RGBW-IC | 8 × 17 | Side | RGBW | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| SB | RH-NF-SB-1025-RGB-IC | 10 × 25 | Side | RGB | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| SB | RH-NF-SB-1025-RGBW-IC | 10 × 25 | Side | RGBW | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| SB | RH-NF-SB-1616-RGB-IC | 16 × 16 | Side | RGB | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| SB | RH-NF-SB-1616-RGBW-IC | 16 × 16 | Side | RGBW | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| 3D | RH-NF-3D-1616-RGB-IC | 16 × 16 | 3D | RGB | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| 360° | RH-NF-360-250-RGB-IC | Ø25 (pitch 250) | 360° | RGB | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
| 360° | RH-NF-360-250-RGBW-IC | Ø25 (pitch 250) | 360° | RGBW | 24V DC | DMX512 / SPI | IP67 | >90 | 30,000 hrs | -20°C ~ +55°C |
DMX512 or SPI — Which Control Protocol?
Both protocols work with the same neon flex hardware. The choice depends on your controller ecosystem and project scale.
DMX512
- ✓ Industry standard for architectural and stage lighting
- ✓ Compatible with most professional lighting consoles
- ✓ Suitable for large installations with long cable runs
- ✓ Easy to integrate with existing show control systems
SPI
- ✓ Direct connection to LED SPI decoders and controllers
- ✓ Higher refresh rate for smooth animation effects
- ✓ Popular for custom signage and creative installations
- ✓ Works with Arduino, Raspberry Pi, and custom controllers
Typical Applications
Architectural Facade Lighting
Building outlines, column accents, and facade feature lighting with programmable color zones and motion effects.
Channel Letter & Signage
Addressable letter fills for retail and hospitality signage — animated brand logos, color-shifting halo effects, and attention-grabbing entrance displays.
Stage & Event Production
DMX512-controlled set pieces, runway outlines, and backdrop lighting that can be programmed for full show synchronization.
Hospitality & Retail Interior
Bar counters, ceiling coves, shelving accents, and feature walls where scene-controlled color adds atmosphere and brand identity.
Bridge & Infrastructure
Handrail outlines, bridge structures, and civic landmark lighting with IP67 weatherproofing for permanent outdoor installation.
Art Installations
3D sculptures, interactive light art, and gallery installations where multi-axis flexibility and pixel control are essential to the design intent.
Ready to Specify?
Tell us your profile, control protocol, color option, and run length. We'll confirm the right model, provide samples, and quote factory-direct pricing.
